Product Details
Place of Origin: China
Brand Name: FAMOUS
Certification: CE,ISO9001,SASO,SGS
Model Number: working roller
Payment & Shipping Terms
Minimum Order Quantity: 1
Price: USD 5000 Per Ton
Packaging Details: Standard seaworthy packing
Delivery Time: 15 days
Payment Terms: L/C, T/T
Supply Ability: 1000 Tons Per Month
Stainless Steel Material: |
Stainless Steel |
Type: |
Work Roller |
Application: |
Steel Plant |
Feature: |
Dust Proof |
Roller Sizes: |
70 |
Shaft/Axle Sizes: |
20 |
Packing: |
Wooden Case |
Plating: |
Customized |
Precision: |
0.01mm |
Stainless Steel Material: |
Stainless Steel |
Type: |
Work Roller |
Application: |
Steel Plant |
Feature: |
Dust Proof |
Roller Sizes: |
70 |
Shaft/Axle Sizes: |
20 |
Packing: |
Wooden Case |
Plating: |
Customized |
Precision: |
0.01mm |
The forged rolls are widely used on some tough stands of hot rolling mill, such as BD stand and blooming stand to perform with excellent strength to avoid some rolling accidents. Meanwhile, it is also a good choice to work on the cold rolling mill as backup roll and work roll. The whole process form melting, casting, forging, heat treatment to final machining and packing is under control of our quality system.
Materials Standards
ANSI, ASTM, ASME, DIN, GB
Materials: High nickel and high chrome heat resistant alloys, cobalt base alloys, like HU, HT, HK, HP, HW, 24/24NbTiZr, 50Cr/50Ni (2.4813), 1.4865, 1.4849, 1.4848, 1.4410, 1.4059, 1.4841, 1.4845, 1.4852, 2.4879 or as per customer's requirements
Guaranteed features of forged steel work rolls for cold rolling
High and uniform hardness after hardening (within 1-2 HSD over the barrel)
Effective layer depth over the radius (20-40 mm)
High thermal fatigue resistance during overall and local heat-up, increased heat resistance (high hardness is maintained for a long time under steady-state thermal conditions of the roll);
Resistance to surface defects, cracking, lamination, scabbing, spalling, tearing, etc.
High surface quality after heat treatment and machining
Favourable distribution and minimal value of residual stresses after hardening and machining
Absence of metallurgical defects and impurities
Absence of flakes, coarse carbide clusters, carbide network, large-pattern acicular martensite and other macro- and microstructural defects
Absence of machining defects
Specification
| Item | MC3 forged work roller steel rolling mill |
| Handcrafte | furnace rolls are comprised of statically cast trunions (ends) welded to a centrifugally cast roll body with our unique locking mechanism. |
| Temperture | can perform in high temperture |
| Advantage | Our dry rolls are comprised of statically cast trunions (ends) welded to a centrifugally cast roll body used in a tunnel furnace |
| our dry rolls will provide abundant fuel savings through reduced heat loss in the furnace |
Packing and preservation
Packing and preservation methods depend on the contract conditions and on the climatic zone where the rolls are going to be supplied, as well as on the transportation and storage conditions.
The items ready to be shipped are covered with a preservative coating – several layers of primer and enamel.
The roll necks are wrapped into anticorrosive paper with polyethylene coating and into waterproof paper.
Storage and service
The rolls should be stored at a non-heated storage, on special shelves, resting on their necks.
Ageing or periodical low tempering is strongly recommended during roll operation life.
