Bailey bridge is standard bridge equipment, adopted extensively and the most popular in the world.While has the characteristics of simple structure, convenient transportation, rapid erection and easy decomposition,is widely used as emergency road againt earthquakes,flood,mud-rock flow.In additional,the bailey bridge truss and structures are used in various configuration as platform,trestle,hung basket,service road,or other supporting structure during Subway,High-speed railway,highway, hydropower station construction.Also,it has the advantage of heavy loading capacity, great stability and long fatigue life being capable of an alternative span, long capacity and mixture form to erect all kinds and usage of temporary bridges, emergency bridges and fixed bridges.
Specifications:
|
Product Name
|
New design portable suspension bridge
|
|
Material
|
Q235/Q345 or as request
|
|
Color
|
Army Green or Customized
|
|
Standard
|
AISI, ASTM, BS, DIN, GB, JIS
|
|
Model
|
CB321Type Bridge
HD200 Type Bridge |
|
Product characteristics/Advantages
|
All robots in the production line are intelligent automated
|
|
Supply Ability
|
50000 Ton/Tons per Year
|
|
Used
|
Steel Structure Bridge,disaster Relief, dangerous bridge reinforcement etc.reinforcement etc.
|
New design portable suspension bridge
1. Speed construction- pre-engineered components.
2. Easy - to handle, transport, assemble, install and reuse.
3. Cost effective to own and re-use in different length bridges.
4. Damaged parts can be easily and quickly replaced from stock.
5. All steel is precision CNC machined and laser cut components.
6. Faithfully replicates the key component of the original Bailey Bridge, including the Panels, Transoms, Stringers, Chesses, Ribands, Rakers, Bracing Frames, End Posts and Sway Braces.
7. Additional sections can be added to increase the length of the bridge.
8. Additional panels can be added to create Double and Triple panel bridges.
9. Includes all fasteners, pins and bearings.
10: Sections can easily be separated for transport.
New design portable suspension bridge
|
321(100)Model steel bridge truss geometric characteristics table
|
|||||
|
Geometric characteristics / Bridge model
|
No reinforce type
|
||||
|
SS
|
DS
|
TS
|
DDR
|
TD
|
|
|
J(cm)
|
250497.2
|
500994.4
|
751491.6
|
2148588.8
|
3222883.2
|
|
W(cm)
|
3578.5
|
7157.1
|
10735.6
|
14817.9
|
22226.8
|
|
Geometric characteristics / Bridge model
|
Reinforce type
|
||||
|
SSR
|
DSR
|
TSR
|
DDR
|
TDR
|
|
|
J(cm)
|
577434.4
|
1154868.8
|
1732303.2
|
4596255.2
|
6894383.8
|
|
W(cm)
|
7699.1
|
15390.3
|
23097.4
|
30641.7
|
45962.6
|
|
321(100)Model steel bridge truss press limited table
|
|||||
|
Internal force / Structure form
|
No reinforce type
|
||||
|
SS
|
DS
|
TS
|
DDR
|
TD
|
|
|
The truss moment
|
788.2
|
1576.4
|
2246.4
|
3265.4
|
4653.2
|
|
The truss scissors
|
245.2
|
490.5
|
698.9
|
490.5
|
698.9
|
|
Internal force / Structure form
|
Reinforce type
|
||||
|
SSR
|
DSR
|
TSR
|
DDR
|
TDR
|
|
|
The truss moment
|
1687.5
|
3375
|
4809.4
|
6750
|
9618.8
|
|
The truss scissors
|
245.2
|
490.5
|
698.9
|
490.5
|
698.9
|
Our company
Our experienced team is focused on your steel bridge project's success, from start to finish. Our proven ability to identify and overcome design inconsistencies, potential problems with erection, and shipping obstacles results in the fabrication of structural steel that is right the first time, helping you avoid costly construction delays.
Proper project coordination and efficient delivery of the structural steel to your bridge project is a key factor in its ultimate success. This is what gives us the leading edge.
From material purchase and tracing, planning compilation, drawing detailing, production arrangement, quality inspection, to on-going painting, packing and delivering, we have separated department to strictly control process, quality and traceability, so that the perfect Bailey/Belay/Baley Bridge can be made.
Finally we would like to emphasize that not like other companies, nearly all machining parts and mechanical accessories are manufactured in our own shop as we have so many wonderful machines and workers inside. In this way, the quality, cost and delivery time can be ensured which eliminates other exterior factors’ influence.
