Rapid Build Steel Structural Truss Delta Bridge Minimal Maintenance Permanent Application

Rapid Build Steel Structural Truss Delta Bridge Minimal Maintenance Permanent Application

Our delta bridge, a proprietary pre-engineered modular bridging solution for different situations and various areas ,which can be suited for road loading capability. Modular steel bridge panel or steel structure members will be used and the length is not fixed,but customized , also can be desig for multi levels up to 100 meters .

Our experienced team is focused on your steel bridge project's success, from start to finish. Our proven ability to identify and overcome design inconsistencies, potential problems with erection, and shipping obstacles results in the fabrication of structural steel that is right the first time, helping you avoid costly construction delays.

Our Delta Bridges provide a proprietary pre-fabricated modular bridging system suited for long-spanning permanent applications on main highways or in rural areas. It uses standardised, interchangeable steel components with full highway loading capability to provide a permanent, lightweight, steel bridging solution which can be configured for clear spans of up to 100 metres. It can also be supplied in multiple spans, supported on intermediate piers, meaning that there is no limitation to the length it can bridge.

Combining the best of off-site fabrication with high speed construction and rapid installation, our Delta Bridges offer significant advantages over more traditional construction techniques which involve major site work. The versatility and robustness of its design means that it can be easily assembled and dismantled, making it equally suited to long-term temporary bridge applications.

Jiuzhou can supply a solution to suit your particular requirements and we are able to accommodate any special load requirements as well as site specific topography, extremes of temperature, high wind loads, and seismic requirements.

Specification:

Advantages:
• Modular
• Rapid-build
• Can be assembled using light plant
• Can be crane built or cantilever launched
• Relocatable
• Transported in standard containers
• Robust
• Designed for high fatigue, permanent applications
• Long life with minimal maintenance
• Preloaded bolted connections
• Parapets as standard
• Factory applied anti-skid deck surfacing as standard
• Optional footwalks

Application:

· Overpass pedestrian walkway
· Highway Road Bridges
· Pedestrian Bridges
· Railway Bridges
· Steel Truss Bridge
· Beam Bridges
· Steel Bailey bridge
· Structural Steel Box Bridge

· Highway Bridges
· Composite Beam Bridge
· Cable-Stayed Bridge
· Floating Bridge
· and so on...

Features:

1. High strength and big stiffness , relative to the concrete bridge can be reduced trabecular high and self-respect
2. Due to the steel isotropic, quality of a material is uniform and modulus of elasticity, that make steel bridge in the working condition and calculation compared with the assumption
3. Steel bridge generally USES factory, site splicing, the construction period is short, processing convenient and not affected by seasonal effect.
4. Steel bridge is suitable for industrialized manufacture and very convenient to transport.
5. Steel bridge is easy to repair and replace,long lifetime,material can be recycled.

We are hornoed, from material purchase and tracing, shop drawing detailing, production arrangement, quality inspection, to on-going painting, packing and delivering, to have separated department to strictly control process, quality and traceability, so that the perfect structural steel bridge can be made.

Meanwhile various standards ranging from Europe EU Standard, America ASTM Standard, British BS Standard, Australia AS/NZS Standard structural steelworks fabrication are also available.

Warmly welcome all friends and clients from International market to visit us and have face talking together!
